TX900-PB-2626(NK) 900MHz Internal PCB Antenna 2dBi IPEX
TX900-PB-2626(NK) 900MHz Internal PCB Antenna 2dBi IPEX
10000 in stock
Couldn't load pickup availability
SKU:tx900-pb-2626nk
Product Overview
The TX900-PB-2626(NK) is a high-performance 900MHz internal PCB patch antenna, specifically engineered for high-reliability wireless communication in the 824-960MHz band. Featuring a 2.0 dBi peak gain and a precision-tuned radiator, it ensures stable signal penetration for LoRa and Sub-GHz applications. Designed with an ultra-compact 26x26mm footprint and an IPEX-1 connector, it is ideal for embedded integration in industrial IoT and smart home devices.
Technical Specifications
| Parameter | Technical Value |
|---|---|
| Frequency Range | 824 - 960 MHz (Supports 868/915MHz) |
| Peak Gain | 2.0 dBi |
| VSWR | ≤ 1.5 |
| Connector Type | IPEX-1 (MHF) |
| PCB Size | 26 * 26 mm |
| Cable Type & Length | RF1.13 / 100mm (Customizable) |
| Impedance | 50 Ω |
| Polarization | Linear Polarization |
Product Details
Ultra-Compact Embedded Design
With a compact 26x26mm PCB dimension, this antenna is designed for internal space-constrained environments. It includes 3M adhesive backing for quick and secure mounting inside device housings.
Gold-Plated IPEX-1 Interface
The industry-standard IPEX-1 (MHF) connector ensures a low-loss, stable connection with wireless modules, facilitating high-frequency signal transmission and mechanical durability.
Professional Test Report
Strictly verified with professional RF instruments: VSWR ≤ 1.5 across the full 900MHz frequency range.
Ideal Applications
LoRa & IoT Gateways
Ideal for embedded LoRaWAN gateways and outdoor smart sensors.
Industrial Data Transmission
Robust signal solutions for wireless remote monitoring and smart grid systems.
Resources
📄 Download Datasheet (PDF)FAQ
Q: Is this antenna compatible with 915MHz modules?
A: Yes, it covers 824-960MHz, which fully includes the 868MHz and 915MHz LoRa frequency bands.
Q: Can it be installed on metal surfaces?
A: For internal PCB antennas, it is recommended to keep them away from large metal objects; a plastic housing is ideal for mounting.
