TX900-PB-1313 900MHz 915MHz Internal PCB Antenna 2.0dBi IPEX
TX900-PB-1313 900MHz 915MHz Internal PCB Antenna 2.0dBi IPEX
10000 in stock
Couldn't load pickup availability
SKU:tx900-pb-1313
Product Overview
The TX900-PB-1313 is a high-efficiency 900MHz (824-960MHz) internal PCB patch antenna, specifically engineered for space-constrained wireless applications. Featuring a 2.0 dBi peak gain and an ultra-compact 13x13mm footprint, it provides stable signal coverage for LoRa and Sub-GHz IoT devices. The antenna comes with a standard IPEX-1 connector and high-quality RF1.13 cable for seamless integration.
Technical Specifications
| Parameter | Technical Value |
|---|---|
| Frequency Range | 824 - 960 MHz (Supports 868/915MHz) |
| Peak Gain | 2.0 dBi |
| VSWR | ≤ 1.5 |
| Connector Type | IPEX-1 (MHF) |
| PCB Size | 13 * 13 mm |
| Cable Type & Length | RF1.13 / 100mm (Customizable) |
| Impedance | 50 Ω |
| Material | PCB + 3M Adhesive Backing |
Product Details
Compact Size & Easy Installation
With a tiny 13x13mm footprint and 3M adhesive backing, this antenna can be easily mounted inside plastic enclosures, ideal for wearable devices and miniature IoT nodes.
Standard IPEX-1 Interface
The gold-plated IPEX-1 connector ensures a secure, low-loss connection to your wireless module, providing consistent RF performance across industrial environments.
Professional Test Report
Verified Performance: VSWR optimized to ≤ 1.5 @ 900MHz for maximum power transfer.
Ideal Applications
LoRa & Smart Home
Compact internal signal solution for smart lighting, locks, and sensors.
Industrial Monitoring
Reliable 868/915MHz data transmission for embedded industrial controllers.
Resources
📄 Download Datasheet (PDF)FAQ
Q: Is it compatible with 915MHz LoRa modules?
A: Yes, it covers the 824-960MHz range, supporting both 868MHz (EU) and 915MHz (US) bands.
Q: Can it be installed on metal surfaces?
A: For internal PCB antennas, avoid sticking directly to metal; a plastic housing is recommended for best performance.
